Model 7200 -39-
KEY PART NO. DESCRIPTION
1 901-3701 5570 Main Welded Body
2 929-3801 Hydraulic Hose Holder
Spring
3 956-3803 Square Tube Jack
3A 956-3803-12 Jack Mount Tube
4 955-3701 Hydraulic Hose 11' Long
5 955-3609 Coupler 3/8" NPT
6 955-3702 Side Hydraulic Pipe (2-Re
-
quired)
7 933-3602 Side Hydraulic Pipe
Bracket Clamp
8 55-0013 Pioneer Coupler Male Tip
9 926-3701-1 Splined Auger Shaft, 23T,
3" Diameter
10 926-3705 Right Side Auger Front
Bearing Style
11 926-3704 Left Side Auger Front
Bearing Style
11A 926-3801-8 Rear Auger Flighting Sup-
port Gusset
12 925-3742 T-Post Auger Hold Down
Assembly w/Nylon
12A 925-3771-9 Nylon Bearing (2-Per Au-
ger)
13 901-3816-65-8 9" Extension Filler Piece
14 901-3816-65-3 Push Off Extension End
Cap Filler
15 901-3816-65-6 Right Front / Left Rear
Push Off Extension
16 901-3816-65-7 Left Front / Right Rear
Push Off Extension
17 851-5013-1.25Z ½"-13 x 1-1/4" Machine
Bolt
18 810-5013-Z ½" Flange Lock Nut
19 901-3816-30 Extension End rail
20 901-3830-5 Rear Splash Guard
21 901-3830-1 Flat Front Splash Guard,
Optional
22 937-0004 1-1/2" Shaft Coupler
W/4-Set Screws
23 923-3705 1-1/2" Front Side Shaft
24 923-3704 1-1/2" Rear Side shaft
25 914-3804 1-1/2" Pillow Block Bear
-
ing
26 55-0091 3/8 X 82" Hydraulic Hose
27 35-0022 3/8 x 3/8 x 4-1/2" Square
Key
28 75-0074 Adjustable Hitch Plate
Welded Assembly
KEY PART NO. DESCRIPTION
29 924-3710 Front Side Shaft Shield As
-
sembly
30 924-3711 Rear Side Shaft Shield
31 955-3803 Black Male Pipe Tee 3/8 x
3/8 x 3/8"
32 901-3830-8 45 Degree Splash Guards,
Optional On Rear
33 933-3701 3" Retaining Ring
34 914-3813 Front Auger Thrust Bearing
Seal
35 914-3812 Front Auger Thrust Bearing
36 921-0005 1-1/2" Locking Set Collar
37 881-1008-5Z 1-08 X 5" Grade 8 Machine
Bolt
39 884-1008 1-08 Grade 8 Top Lock Nut
40 901-3801-40 Hydraulic Hose / Scraper
Holder Ring
41 803-2520-.75Z 1/4-20 x 3/4" Socket Flat
Cap Screw
42 955-3754 3/4" Hose Tube Clamp
43 901-3801-59 Center Shaft Shield
44 901-3711 Cross Support Pipe W/Tabs
BOX, AUGERS & SIDE SHAFT
