Meyer 7200 - Page 43

Model 7200 -43-
KEY PART NO. DESCRIPTION
1 901-3834-1 RH, 4-Point Paddle 3/8"
4/6-Per RH Spinner
(Lower) 2-Per LH (Upper)
901-3834-1-AR
Optional AR400
RH, 4-Point Paddle 3/8"
4/6-Per RH Spinner
(Lower) 2-Per LH (Upper)
(Optional)
2 901-3835-1 LH, 4-Point Paddle 3/8"
4/6-Per LH Spinner
(Lower) 2-Per RH (Upper)
901-3835-1-AR
Optional AR400
LH, 4-Point Paddle 3/8"
4/6-Per LH Spinner
(Lower) 2-Per RH (Upper)
(Optional)
3 19-0029 Left Spinner Gearbox
4 35-0004 3/8 x 3/8 x 2" Square Key
5 937-0005 Shaft Coupler 1-3/4" Bore,
(4-Required)
6 19-0030 Right Spinner Gearbox
7 19-0036 Corner Gearbox, (1000
RPM) Standard
19-0035 Corner Gearbox, (540
RPM) Optional
8 901-3704 R.H. Spinner Assembly
Less Paddles (Prior to Se-
rial #SI067200308)
901-3715 R.H. Spinner Assembly
Less Paddles (Serial
#SI067200308 & Later)
8A 901-3704-6 Bottom Spinner Shaft Only
(Welded In)
9 901-3703 L.H. Spinner Assembly
Less Paddles (Prior to Se
-
rial #SI067200308)
901-3714 L.H. Spinner Assembly
Less Paddles (Serial
#SI067200308 & Later)
10 914-3602 1-1/2" 4-Bolt Bearing
11 937-0005K 1-3/4" Coupler Assy. Kit
W/Bolts & Keys
12 924-3703 Rear Main Shield Assem
-
bly
13 924-3704 Right Rear Gearbox
Shield Assembly
14 33-1002 SMV Sign Bracket
15 808-1.75-2.5-14 1-3/4I.D. x 2-1/2O.D. x 14
Ga. M.B.
16 933-3709 Gearbox Spinner Spacer
17 851-5013-1.5Z ½-13 x 1-1/2" Grade 5 Ma
-
chine Bolt
18 815-5013-Z ½-13 Nylon Insert Locknut
19 901-3704-1 1-3/4" Bore x 3" Long
Splined Hub
KEY PART NO. DESCRIPTION
20 32-0021 2" Hair Pin Clip
21 32-0022 6" Lanyard
22 32-0023 3/8 x 3/4" Clevis Pin
23 851-3824-1.5Z 3/8-24 x 1-1/2" Fine
Thread Grade 5 Bolt
24 815-3824-Z 3/8-24 Nylon Insert
Locknut
25 933-3632 Copper Tube Grease Line
36" (Includes zerks, fit
-
tings)
26 933-3625 Copper Tube Grease Line
55" (Includes zerks, fit
-
tings)
27 901-3834-2 Left Hand Paddle Mount
Brackets
28 901-3835-2 Right Hand Paddle Mount
Brackets
29 901-3704-8 Paddle Reinforcing
Bracket (6 or 8-Per Spin
-
ner)
30 937-0009-2 Coupler Chain
31 937-0010-1 1-3/4” Chain Coupler Half
32 937-0009-1 1-1/2" Chain Coupler Half
33 937-0009 1-1/2" Chain Coupler Kit
34 901-3720-2 Left Spinner Paddle Riser
(Serial #SI047200228 &
Earlier)
901-3720-5 Left Spinner Paddle Riser
(Serial
#SI047200229-SI0672003
07)
35 901-3720-1 Right Spinner Paddle
Riser (Serial
#SI047200228 & Earlier)
901-3720-6 Right Spinner Paddle
Riser (Serial
#SI047200229-SI0672003
07)
36 937-0010 1-3/4” Chain Coupler Kit
37 901-13702-2 Left Cupped Lower Paddle
(Serial #SI067200308 &
Later)
38 901-13702-1 Right Cupped Lower Pad
-
dle (Serial #SI067200308
& Later)
SPINNERS & GEARBOX SHAFT DRIVE
