Mi Swaco 414

50
Index
No.
Swaco
Part No.
Description Qty.
1 84-01-298 Round Nut 80 mm 1
2 84-01-870 Lock Washer 80 mm 1
3 96-10-315 Bushing 1
4 84-01-370 Pin, Grooved 5/16 x 1 inch 1
5 96-10-148 Flange 1
6 84-01-972 SHCS, SS, M16 x 30 mm 6*
7 84-01-964 SHSS, SS, M12 x 15 mm 3
8 84-01-520 SHCS, M12 x 90 mm 4
9 96-10-431 Washer Spacer 4
10 96-10-399 Ring Labyrinth 1*
11 28-40-015 Grease Fitting 2
12 96-10-145 Bearing Housing 1
13 84-01-034 Cylindrical Roller Bearing SKF NU 1020 M/C3 1
14 84-01-336 O-ring 1
15 96-10-403 Spacer Ring 1
16 84-01-322 Lip Seal Ring 2
17 96-10-354 Fat Valve Disc 1
20 96-10-398 Guard Ring 1
21 96-10-352 Deflector 1
23 84-01-310 O-ring 1
25 96-10-392 Cleansing Plug 2
26 84-01-324 O-ring 2
27 96-10-149 End Piece 1
28 84-01-360 SHSS,, SS, M10 x 25 mm 4
29 84-01-462 SHCS, SS, M10 x 45 mm 16
30 84-01-443 Lip Seal Ring 1
31 84-01-031 Cylindrical Roller Bearing SKF NU 216 1
32 84-01-433 Snap Ring 1
33 84-01-421 O-ring 1
34 96-10-411 Seal Lining 1
35 84-01-405 Lip Seal Ring 1
36 84-01-991 SHSS, SS, M10 x 12 mm 2
37 96-10-377 Bearing Holder 1
38 84-01-454 SHSS, SS, M8 x 20 mm 6
40 84-01-431 Snap Ring 1
41 96-10-406 Thrust Ring 1
42 84-01-023 Ball Bearing SK 7316B 1
43 96-10-378 Ball Bearing Holder 1
Diagram 3 (414 Centrifuge Gearbox End Assembly Parts List)
