MicaSense RedEdge-M User Manual

November 2020
Page 13 of 21
Pin #
Signal
Direction
1
5.0 V DC Output
Output From Camera
2
DLS 2/GPS RX
Output From Camera
3
DLS 2/GPS TX
Input To Camera
4
GPS IO 0
(Configurable)
Input To Camera/Output from
Camera
5
GPS IO 1
(Configurable)
Input To Camera/Output from
Camera
6
Ground
Ground
Connector on Camera
Hirose DF13A-6P-1.25H(51)
Mating Connector
Hirose DF13-6S-1.25C
28AWG wire recommended
Serial and Ethernet Data (“COMM”): This connector is available for tighter integration
with host aircraft. It includes a standard TTL-level serial port as well as an Ethernet port.
Documentation for the communications protocol is available by contacting MicaSense.
Pin #
Signal
Direction
1
Serial RX (3.3 V)
Output From Camera
2
Serial TX (3.3 V)
Input To Camera
3
Serial Ground
Ground
4
Ethernet RX P (B+)
Output From Camera
5
Ethernet RX N (B-)
Output From Camera
6
Ethernet Line Ground
Ground
7
Ethernet TX P (A+)
Input To Camera
8
Ethernet TX N (A-)
Input To Camera
9
Ethernet RX P 1G (D+)
Output From Camera
10
Ethernet RX N 1G (D-)
Output From Camera
11
Ethernet TX P 1G (C+)
Input To Camera
12
Ethernet TX N 1G (C-)
Input To Camera
Connector on Camera
Hirose DF13A-12P-1.25H(51)
Mating Connector
Hirose DF13-12S-1.25C
28AWG wire recommended
