Figure 7-12. LED Interface
MCU_LED1
MCU_LED2
MCU_LED3
MCU_LED4
MCU_LED5
MCU_LED6
MCU_LED7
MCU_LED8
LED(MCU)
200R
0603
1%
R406
200R
0603
1%
R409
200R
0603
1%
R411
200R
0603
1%
R412
200R
0603
1%
R413
200R
0603
1%
R414
200R
0603
1%
R415
200R
0603
1%
R421
GREEN
D401
GREEN
D402
GREEN
D403
GREEN
D404
GREEN
D405
GREEN
D406
GREEN
D407
GREEN
D411
3V3_GEN
BM83 EVB
Appendix A: BM83 EVB Reference Schematics
© 2019 Microchip Technology Inc.
User Guide
DS50002902A-page 49
