9. Jumper settings on J404 and J405 to connect BM83 module I2S with STA369BW Audio Daughter Board I2S:
9.1. Mount a jumper on pin1 of J404 and J405.
9.2. Mount a jumper on pin2 of J404 and J405.
9.3. Mount a jumper on pin3 of J404 and J405.
9.4. Mount a jumper on pin4 of J404 and J405.
9.5. Mount a jumper on pin5 of J404 and J405.
9.6. Open pin6 of J404 and J405.
9.7. Open pin7 of J404 and J405.
10. Put the SW300 switch to OFF position.
11. By default, the board is configured with hardware (HW) I2C settings. For more details on the software (SW)
I2C settings, refer to I2C Interface section in the IS2083 SDK User’s Guide (DS50002894).
12. Mount a jumper on pin2 and pin3 of the JP203.
With the above settings, the user can plug in the 15V DC adapter and perform the application demo in Embedded
mode with the appropriate firmware image. This firmware image for the Embedded mode is available at
www.microchip.com/BM83.
