Microchip Technology dsPIC33 series User Manual

 2018 Microchip Technology Inc. DS70005340A-page 27
CAN FD Protocol Module
Register 3-25: C1TXREQH: CAN Transmit Request Register High
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
TXREQ<31:24>
bit 15 bit 8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
TXREQ<23:16>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-0 TXREQ<31:16>: Message Send Request bits
TXEN =
1 (object configured as a transmit object):
Setting this bit to ‘1’ requests sending a message. The bit will automatically clear when the message(s)
queued in the object is (are) successfully sent. This bit can NOT be used for aborting a transmission.
TXEN =
0 (object configured as a receive object):
This bit has no effect.
Register 3-26: C1TXREQL: CAN Transmit Request Register Low
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
TXREQ<15:8>
bit 15 bit 8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
TXREQ<7:1> TXREQ0
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-1 TXREQ<15:0>: Message Send Request bits
TXEN =
1 (object configured as a transmit object):
Setting this bit to ‘1’ requests sending a message. The bit will automatically clear when the message(s)
queued in the object is (are) successfully sent. This bit can NOT be used for aborting a transmission.
TXEN =
0 (object configured as a receive object):
This bit has no effect.
bit 0 TXREQ0: Transmit Queue Message Send Request bit
Setting this bit to ‘1’ requests sending a message. The bit will automatically clear when the message(s)
queued in the object is (are) successfully sent. This bit can NOT be used for aborting a transmission.
