CAN FD Protocol Module
3.0 CONTROL REGISTERS
CAN FD operations are controlled using the following Special Function Registers (SFRs). The
following registers are described later in this section:
• Register 3-1: C1CONH
• Register 3-2: C1CONL
• Register 3-3: C1NBTCFGH
• Register 3-4: C1NBTCFGL
• Register 3-5: C1DBTCFGH
• Register 3-6: C1DBTCFGL
• Register 3-7: C1TDCH
• Register 3-8: C1TDCL
• Register 3-9: C1TBCH
• Register 3-10: C1TBCL
• Register 3-11: C1TSCONH
• Register 3-12: C1TSCONL
• Register 3-13: C1VECH
• Register 3-14: C1VECL
• Register 3-15: C1INTH
• Register 3-16: C1INTL
• Register 3-17: C1RXIFH
• Register 3-18: C1RXIFL
• Register 3-19: C1RXOVIFH
• Register 3-20: C1RXOVIFL
• Register 3-21: C1TXIFH
• Register 3-22: C1TXIFL
• Register 3-23: C1TXATIFH
• Register 3-24: C1TXATIFL
• Register 3-25: C1TXREQH
• Register 3-26: C1TXREQL
• Register 3-27: C1FIFOBAH
• Register 3-28: C1FIFOBAL
• Register 3-29: C1TXQCONH
• Register 3-30: C1TXQCONL
• Register 3-31: C1TXQSTA
• Register 3-32: C1FIFOCONxH
• Register 3-33: C1FIFOCONxL
• Register 3-34: C1FIFOSTAx
• Register 3-35: C1TEFCONH
• Register 3-36: C1TEFCONL
• Register 3-37: C1TEFSTA
• Register 3-38: C1FOUAxH
• Register 3-39: C1FOUAxL
• Register 3-40: C1TEFUAH
• Register 3-41: C1TEFUAL
• Register 3-42: C1TXQUAH
• Register 3-43: C1TXQUAL
• Register 3-44: C1TRECH
• Register 3-45: C1TRECL
• Register 3-46: C1BDIAG0H
• Register 3-47: C1BDIAG0L
• Register 3-48: C1BDIAG1H
• Register 3-49: C1BDIAG1L
• Register 3-50: C1FLTCONxH
• Register 3-51: C1FLTCONxL
• Register 3-52: C1FLTOBJxH
• Register 3-53: C1FLTOBJxL
• Register 3-54: C1MASKxH
• Register 3-55: C1MASKxL
