DS70005340A-page 44  2018 Microchip Technology Inc.
Register 3-46: C1BDIAG0H: CAN Bus Diagnostics Register 0 High
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
DTERRCNT<7:0>
bit 15 bit 8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
DRERRCNT<7:0>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-8 DTERRCNT<7:0>: Data Bit Rate Transmit Error Counter bits
bit 7-0 DRERRCNT<7:0>: Data Bit Rate Receive Error Counter bits
Register 3-47: C1BDIAG0L: CAN Bus Diagnostics Register 0 Low
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
NTERRCNT<7:0>
bit 15 bit 8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
NRERRCNT<7:0>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-8 NTERRCNT<7:0>: Nominal Bit Rate Transmit Error Counter bits
bit 7-0 NRERRCNT<7:0>: Nominal Bit Rate Receive Error Counter bits
