CAN FD Protocol Module
Register 3-44: C1TRECH: CAN Transmit/Receive Error Count Register High
U-0 U-0 U-0 U-0 U-0 U-0 U-0 U-0
— — — — — — — —
bit 15 bit 8
U-0 U-0 R-1 R-0 R-0 R-0 R-0 R-0
— — TXBO TXBP RXBP TXWARN RXWARN EWARN
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-6 Unimplemented: Read as ‘0’
bit 5 TXBO: Transmitter in Error State Bus Off bit (TERRCNT<7:0> > 255)
In Configuration mode, TXBO is set since the module is not on the bus.
bit 4 TXBP: Transmitter in Error State Bus Passive bit (TERRCNT<7:0> > 127)
bit 3 RXBP: Receiver in Error State Bus Passive bit (RERRCNT<7:0> > 127)
bit 2 TXWARN: Transmitter in Error State Warning bit (128 > TERRCNT<7:0> > 95)
bit 1 RXWARN: Receiver in Error State Warning bit (128 > RERRCNT<7:0> > 95)
bit 0 EWARN: Transmitter or Receiver is in Error State Warning bit
Register 3-45: C1TRECL: CAN Transmit/Receive Error Count Register Low
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
TERRCNT<7:0>
bit 15 bit 8
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
RERRCNT<7:0>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-8 TERRCNT<7:0>: Transmit Error Counter bits
bit 7-0 RERRCNT<7:0>: Receive Error Counter bits
