Microchip Technology dsPIC33 series User Manual

 2018 Microchip Technology Inc. DS70005340A-page 35
CAN FD Protocol Module
Register 3-34: C1FIFOSTAx: CAN FIFO Status Register x (x = 1 to 31)
U-0 U-0 U-0 R-0 R-0 R-0 R-0 R-0
— — — FIFOCI4
(1)
FIFOCI3
(1)
FIFOCI2
(1)
FIFOCI1
(1)
FIFOCI0
(1)
bit 15 bit 8
R-0 R-0 R-0 HS/C-0 HS/C-0 R-0 R-0 R-0
TXABT
(3)
TXLARB
(2)
TXERR
(2)
TXATIF RXOVIF TFERFFIF TFHRFHIF TFNRFNIF
bit 7 bit 0
Legend: HS = Hardware Settable bit C = Clearable bit
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-13 Unimplemented: Read as ‘0’
bit 12-8 FIFOCI<4:0>: FIFO Message Index bits
(1)
TXEN = 1 (FIFO configured as a transmit buffer):
A read of this register will return an index to the message that the FIFO will next attempt to transmit.
TXEN =
0 (FIFO configured as a receive buffer):
A read of this register will return an index to the message that the FIFO will use to save the next
message.
bit 7 TXABT: Message Aborted Status bit
(3)
1 = Message was aborted
0 = Message completed successfully
bit 6 TXLARB: Message Lost Arbitration Status bit
(2)
1 = Message lost arbitration while being sent
0 = Message did not lose arbitration while being sent
bit 5 TXERR: Error Detected During Transmission bit
(2)
1 = A bus error occurred while the message was being sent
0 = A bus error did not occur while the message was being sent
bit 4 TXATIF: Transmit Attempts Exhausted Interrupt Pending bit
TXEN =
1 (FIFO configured as a transmit buffer):
1 = Interrupt is pending
0 = Interrupt is not pending
TXEN =
0 (FIFO configured as a receive buffer):
Unused, reads as ‘0’.
bit 3 RXOVIF: Receive FIFO Overflow Interrupt Flag bit
TXEN = 1 (FIFO configured as a transmit buffer):
Unused, reads as ‘0’.
TXEN = 0 (FIFO configured as a receive buffer):
1 = Overflow event has occurred
0 = No overflow event occurred
Note 1: FIFOCI<4:0> gives a zero-indexed value to the message in the FIFO. If the FIFO is 4 messages deep
(FSIZE = 3), FIFOCIx will take on a value of 0 to 3, depending on the state of the FIFO.
2: This bit is updated when a message completes (or aborts) or when the FIFO is reset.
3: This bit is reset on any read of this register or when the TXQ is reset.
