Register 3-38: C1FIFOUAxH: CAN FIFO User Address Register x (x = 1 to 31) High
(1)
R-x R-x R-x R-x R-x R-x R-x R-x
FIFOUA<31:24>
bit 15 bit 8
R-x R-x R-x R-x R-x R-x R-x R-x
FIFOUA<23:16>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-0 FIFOUA<31:16>: FIFO User Address bits
TXEN =
1 (FIFO configured as a transmit buffer):
A read of this register will return the address where the next message is to be written (FIFO head).
TXEN = 0 (FIFO configured as a receive buffer):
A read of this register will return the address where the next message is to be read (FIFO tail).
Note 1: This register is not ensured to read correctly in Configuration mode and should only be accessed when the
module is not in Configuration mode.
Register 3-39: C1FIFOUAxL: CAN FIFO User Address Register x (x = 1 to 31) Low
(1)
R-x R-x R-x R-x R-x R-x R-x R-x
FIFOUA<15:8>
bit 15 bit 8
R-x R-x R-x R-x R-x R-x R-x R-x
FIFOUA<7:0>
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-0 FIFOUA<15:0>: FIFO User Address bits
TXEN =
1 (FIFO configured as a transmit buffer):
A read of this register will return the address where the next message is to be written (FIFO head).
TXEN = 0 (FIFO configured as a receive buffer):
A read of this register will return the address where the next message is to be read (FIFO tail).
Note 1: This register is not ensured to read correctly in Configuration mode and should only be accessed when the
module is not in Configuration mode.
