dsPIC33CH Curiosit
y Development Board User’s Guid
e
DS50000000A-page
4
Advance
Information
2018 Microchip Technology Inc.
NOTES:
3
5
Table of Contents
Default Chapter
3
Table of Contents
3
Preface
5
Chapter 1. Introduction
11
Schematics and Bill of Materials (BOM)
12
Chapter 2. Hardware
13
Powering the Board
13
USB Power
13
External Power
13
Using the Programmed Demo Firmware
14
Reprogramming and Debugging the Dspic33Ch128Mp508 Device (U1)
14
Using the Isolated USB-UART Interface
15
Circuit Details
15
Jumpers/Headers/Connectors
15
SMPS Hardware Overcurrent Protection
16
SMPS Hardware Overvoltage Protection
17
PWM DAC/DC Bias Generator
17
Transient Load Tester Circuit
18
Low-Side Current Sensing
19
High-Side Current Sensing
20
Appendix A. Schematics
21
Appendix B. Bill of Materials
27
Worldwide Sales and Service
30
