dsPIC33CH CURIOSITY DEVELOPMENT
BOARD USER’S GUIDE
2018 Microchip Technology Inc.
Advance Information
DS50002762A-page 27
Appendix B. Bill of Materials (BOM)
TABLE B-1: dsPIC33CH CURIOSITY DEVELOPMENT BOARD BILL OF MATERIALS
Qty. Designator Description Mfg. 1 Mfg. 1 Part # Mfg. 2 Mfg. 2 Part #
28 C1, C2, C3, C4, C6,
C7, C8, C9, C11,
C12, C13, C16, C17,
C18, C19, C20, C21,
C24, C25, C27, C28,
C29, C32, C33, C37,
C41, C49, C50
Capacitor Ceramic, 0.1 µF, 25V,
10%, X7R, SMD, 0603
Murata
Electronics
®
GRM188R71E104KA01D Wurth Elektronik 885012206071
5 C5, C30, C31, C48,
C51
Capacitor Ceramic, 1 µF, 16V,
10%, X7R, SMD, 0603
Taiyo Yuden
Co., Ltd.
EMK107B7105KA-T Wurth Elektronik 885012206052
9 C10, C14, C34,
C35, C36, C42,
C47, C53, C55
Capacitor Ceramic, 10 µF, 25V,
10%, X5R, SMD, 0805
Murata
Electronics
GRM21BR61E106KA73L
5 C15, C22, C26,
C40, C54
Capacitor Ceramic, 0.010 µF,
25V, 10%, X7R, SMD, 0603
Yageo
Corporation
CC0603KRX7R8BB103 Wurth Elektronik 885012206065
2 C23, C39 Capacitor Ceramic, 2.2 µF, 10V,
10%, X7R, SMD, 0603
Murata
Electronics
GRM188R71A225KE15D Wurth Elektronik 885012206027
1 C57 Capacitor Aluminum, 100 µF,
20%, 25V, Low-ESR, Radial
KEMET ESY107M025AE3AA
19 R1, R3, R5, R24,
R33, R35, R38, R44,
R46, R48, R49, R50,
R51, R64, R65, R82,
R88, R89, R102
Resistor TKF, 10k, 1%,
1/10W, SMD, 0603
Panasonic
®
-
ECG
ERJ-3EKF1002V
17 R2, R4, R6, R8, R14,
R19, R25, R30, R34,
R54, R57, R68, R72,
R73, R75, R79, R85
Resistor TKF, 1k, 1%, 1/10W,
SMD, 0603
Panasonic -
ECG
ERJ-3EKF1001V
8 R7, R23, R31, R37,
R53, R70, R80, R99
Resistor TKF, 4.7k, 1%, 1/10W,
SMD, 0603
ROHM
Semiconductor
MCR03EZPFX4701
3 R9, R10, R58 Resistor TKF, 820R, 1%,
1/10W, SMD, 0603
Stackpole
Electronics, Inc.
RMCF0603FT820R
8 R11, R12, R13, R15,
R29, R32, R36, R98
Resistor TKF, 330R, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF3300V
3 R16, R62, R66 Resistor TKF, 270R, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF2700V
1 R17 Resistor, Variable, 10K, 20%,
TH
Alps Electric
Co., Ltd.
RK09K1130A5R
3 R18, R83, R103 Resistor TKF, 470R, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF4700V
9 R20, R28, R47,
R52, R55, R56,
R61, R87, R95
Resistor TKF, 100R, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF1000V
1 R26 Resistor, SMD, 3.57 kOhm, 1%,
1/10W, 0603
Vishay/Dale CRCW06033K57FKEA
1 R27 Resistor TKF, 3.16k, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF3161V
3 R42, R45, R76 Resistor TKF, 100k, 1%,
1/10W, SMD, 0603
Panasonic -
ECG
ERJ-3EKF1003V
6 R59, R63, R74,
R92, R93, R94
Resistor TKF, 1R, 1%, 1/4W,
SMD, 1206
ROHM
Semiconductor
MCR18EZHFL1R00
1 R60 Resistor TKF, 0R, 1/10W, SMD,
0603
Panasonic -
ECG
ERJ-3GSY0R00V
6 R67, R77, R90,
R91, R100, R101
Resistor TKF, 20k, 1%, 1/10W,
SMD, 0603
Panasonic -
ECG
ERJ-3EKF2002V
To Next Page
