dsPIC33CH Curiosity Development Board User’s Guide
DS50002762A-page 28
Advance Information
2018 Microchip Technology Inc.
1 R84 Resistor TKF, 2.2k, 1%, 1/10W,
SMD, 0603
Panasonic -
ECG
ERJ-3EKF2201V
1 R96 Resistor TKF, 20R, 1%, 1/8W,
SMD, 0805
ROHM
Semiconductor
MCR10EZHF20R0
1 R97 Resistor TKF, 150R, 1%,
1/10W, SMD, 0603
Stackpole
Electronics, Inc.
RMCF0603FT150R
1 L1 Inductor, 33 µH, 1.7A, 0.120R,
TH
Bourns
®
, Inc. RLB0914-330KL Wurth Elektronik 7447471330
2 D2, D5 Diode Schottky, 30V, 1A, PMDU ROHM
Semiconductor
RSX101MM-30TR
1 D6 Diode Rectifier,
MMBD914LT1G, 1V, 10 mA,
100V, SMD, SOT-23-3
ON
Semiconductor
®
MMBD914LT1G
2 D8, D9 Diode Schottky, BAT54,
800 mV, 200m A, 30V,
SOT-23-3
Diodes
Incorporated
®
BAT54-7
2 LED1, LED2 Diode LED Red, 2V, 20 mA,
104 mcd, Diffuse, SMD, 0805
OSRAM Opto
Semiconductors
GmbH.
LS R976-NR-1 Wurth Elektronik 150080RS75000
1 LED3 Diode LED Tri Red, Green, Blue Cree, Inc. CLX6D-FKB-CMPQSGKBB7A363
1 LED5 Diode LED Green, 2.2V, 25 mA,
15 mcd, Clear, SMD, 0603
Kingbright
Electronics Co.,
Ltd.
APT1608SGC Wurth Elektronik 150060GS75000
3 Q3, Q11, Q12 Transistor BJT PNP,
MMBT3906, -40V, -200 mA,
300 mW, SOT-23-3
Diodes
Incorporated
MMBT3906-7-F
5 Q4, Q5, Q7, Q9,
Q10
Transistor BJT NPN,
MMBT3904, 40V, 200 mA,
310 mW, SOT-23-3
Diodes
Incorporated
MMBT3904-7-F
1 Q1 MOSFET P-CH, 20V, 0.1A,
SOT-723-3
ROHM
Semiconductor
RZM001P02T2L
1 Q6 MOSFET P-CH, 30V, 2A,
SOT-23
Infineon
Technologies AG
BSS308PEH6327XTSA1
1 Q13 MOSFET P-CH, 20V, 4.3A,
SOT-23
Diodes
Incorporated
DMP2100U-7
2 Q2, Q8 MOSFET N-CH, 25V,
MCP87130T-U/LC
Microchip
Technology Inc.
MCP87130T-U/LC
4 J3, J8 Connector Header-2.54 Female,
1x8, 0.100" (2.54 mm), Tin,
Through-Hole
Sullins
Connector
Solutions
PPTC081LFBN-RC Wurth Elektronik 61300811821
2 J10, J13 Connector Header-2.54 Male,
1x2, Gold, 5.84MH, TH, Vertical
FCI 77311-118-02LF Wurth Elektronik 61300211121
2 _J10, _J13 Mechanical Hardware Jumper
Cap, 2.54 mm, 1x2
3M 969102-0000-DA Wurth Elektronik 60900213421
2 J11, J12 Connector Header-2.54 Female,
2x18, 0.100" Pitch, Gold, TH
Samtec, Inc. SSW-118-01-G-D Wurth Elektronik 61303621821
2 J16, J20 Connector USB 2.0 micro-B
Female, TH/SMD, R/A
FCI 10118194-0001LF Wurth Elektronik 629105136821
1 J18 Connector Header-2.54 Female,
2x5, 0.100", Gold, TH
Samtec, Inc. SSQ-105-02-G-D Wurth Elektronik 61301021821
1 J21 Connector Screw Terminal,
5 mm, 1x2, Female, 12-
26AWG, 18A, TH, R/A
Phoenix Contact
GmbH & Co.
1935161 Wurth Elektronik 691102710002
4 S1, S2, S3, S4 Switch Tact, SPST, 12V, 50 mA,
PTS645SM43SMTR92 LFS,
SMD
C&K
Components
PTS645SM43SMTR92 LFS Wurth Elektronik 430182043816
4 PAD1, PAD2, PAD3,
PAD4
Mechanical Hardware Rubber
Pad, Bumpon Hemisphere,
0.44" x 0.20", Black
3M SJ-5003 (BLACK)
1 TH1 PTC Resettable, 0.50A, 16V,
Chip, 1210
Bel Fuse Inc. 0ZCB0050FF2G
1 U11 Digital ISO, 2.5KV,
General Purpose, 8-SOIC
Silicon
Laboratories
®
Inc.
SI8422AB-D-IS
TABLE B-1: dsPIC33CH CURIOSITY DEVELOPMENT BOARD BILL OF MATERIALS (CONTINUED)
Qty. Designator Description Mfg. 1 Mfg. 1 Part # Mfg. 2 Mfg. 2 Part #
