Bill of Materials (BOM)
 2018 Microchip Technology Inc. Advance Information DS50002762A-page 29
1 U5 IC Logic Gate, UHS, 2-INP,
SC70-6
Fairchild
Semiconductor
®
/
ON
Semiconductor
NC7SZ57P6X
1 U10 IC Logic Gate, UHS, 2-INP,
SC70-6
Fairchild
Semiconductor/
ON
Semiconductor
NC7SZ58P6X
1 U1 dsPIC33CH128MP508,
TQFP-80
Microchip
Technology Inc.
dsPIC33CH128MP508-I/PT
1 U4 Microchip MCU, 16-Bit,
32 MHz, 256 kB, 16 kB,
PIC24FJ256GB106-I/PT,
TQFP-64
Microchip
Technology Inc.
PIC24FJ256GB106-I/PT
1 U6 Microchip Memory Serial
EEPROM, 256k, SPI,
25LC256-I/SN, SOIC-8
Microchip
Technology Inc.
25LC256T-I/SN
1 U7 Microchip Analog Op Amp,
2-Ch, 10 MHz,
MCP6292T-E/MS, MSOP-8
Microchip
Technology Inc.
MCP6292T-E/MS
1 U8 Microchip Analog Op Amp,
1-Ch, 1 MHz, MCP6001T-I/OT,
SOT-23-5
Microchip
Technology Inc.
MCP6001T-I/OT
1 U9 Microchip Interface, USB, I
2
C,
UART, MCP2221A-I/ST,
TSSOP-14
Microchip
Technology Inc.
MCP2221A-I/ST
1 U12 MIC5528-3.3 Linear Voltage
Regulator IC, Positive, Fixed,
1 Output, 3.3V, 500 mA,
6-TDFN (1.2x1.2)
Microchip
Technology Inc.
MIC5528-3.3YMT-TR
1 X1 MEMS Oscillator, 8.0000 MHz,
2.5x2.0 mm
Microchip
Technology Inc.
DSC6011JI1A-008.0000
1 X3 MEMS Oscillator, 12.0000 MHz,
2.5x2.0 mm
Microchip
Technology Inc.
DSC6011JI1A-012.0000
Do Not Populate Parts Listed Below
3 C38, C45, C52 Unpopulated pad
3 C43, C44, C46 Unpopulated pad
2 D1, D7 Unpopulated pad
3 J1, J14, J19 Unpopulated pad
2 J2, J15 Unpopulated pad
1 J9 Unpopulated pad
1 J17 Unpopulated pad
7 R21, R22, R69,
R71, R78, R81, R86
Unpopulated pad
4 R39, R40, R41, R43 Unpopulated pad
1 TP5 Unpopulated pad
1 X2 Unpopulated pad
TABLE B-1: dsPIC33CH CURIOSITY DEVELOPMENT BOARD BILL OF MATERIALS (CONTINUED)
Qty. Designator Description Mfg. 1 Mfg. 1 Part # Mfg. 2 Mfg. 2 Part #
