AN3118
APPENDIX Q: ENABLING GOOGLE
FAST PAIRING
FEATURES
Q.1 Enabling GFP in Config GUI Tool
To enable Google Fast Pair using the Config GUI Tool:
1. Open the Config GUI Tool and go to the BLE
Setup tab as shown in the following figure.
FIGURE 108: ENABLING GFP USING CONFIG GUI TOOL
2. The default value of Tx Power is -27 dB and can
be changed.
3. Battery level can be Enabled/Disabled.
4. Advertising Data Setting will be greyed out as
shown in the following figure.
5. Beacon data can be disabled using the Config
GUI Tool as shown in the following figure.
Note: By default, the Model ID and Private Key
are assigned by Google. Thus, DO NOT
change these values.
