RN4870/71
DS50002489G-page 12 2016-2023 Microchip Technology Inc.
TABLE 2-3: CURRENT CONSUMPTION
(1)
Parameter Min. Typ. Max. Units
Supply Current
TX Mode Peak Current at V
DD = 3V, TX = 0 dBm, Buck Mode — 10 at +25°C 13 at +75°C/+85°C mA
RX Mode Peak Current at V
DD = 3V, Buck Mode — 10 at +25°C 13 at +75°C/+85°C mA
Low-Power Mode Current
(2)
— 60 at +25°C — µA
Shutdown Low-Power Mode 1 — 2.9 µA
Note 1: The current measurements are characterized across a sample of the RN4870/71 module at room
temperature (+25°C), unless otherwise noted.
2: For more details on Low-Power mode, refer to the “RN4870/71 Bluetooth
®
Low Energy Module User’s
Guide” (DS50002466).
TABLE 2-4: CURRENT CONSUMPTION DURING APPLICATION MODE
Test Mode
Interval
(ms)
Average Current Consumption
Advertising
(1,2,3)
20 1.061 mA
50 505 µA
100 298 µA
500 113 µA
1000 89 µA
Connected
(1,2,4)
18.75 2.23 mA
50 2.13 mA
100 2.10 mA
500 83 µA
1000 80 µA
Note 1: These measurements are done at an operating temperature of +25°C at 3.3V and are characterized
across a sample of the RN4870/71 module.
2: Measurements taken with Version 1.18 firmware loaded onto the module.
3: The advertising packet data payload is approximately 15 bytes in length.
4: The amount of data being transmitted between two peer devices can affect the average current measured.
The average current measurements are done with only the necessary Bluetooth
®
packets being
exchanged to keep the connection active at the stated interval.
