SENSOR: POT
Wiring for three wires pot with CENTER, LOW (left) and HIGH (right) leads. Resistance between
LOW and CENTER leads should decrease towards CCW limit.
POTENTIOMETER ROTATOR PORT NAME PIN NUMBER
LOW side SENSOR LO 1
CENTER SENSOR C 2
HIGH side SENSOR HI 3
SENSOR: RHEO
Wiring for two wire rheostat with LOW and HIGH leads. Resistance between LOW and HIGH
leads should decrease towards CCW limit.
RHEOSTAT ROTATOR PORT NAME PIN NUMBER
LOW side SENSOR LO 1
HIGH side SENSOR HI 3
SENSOR: REED CONTACT
Wiring for simple magnetic reed contact, leads have no polarity and can be reversed without
any adverse effect.
RHEOSTAT ROTATOR PORT NAME PIN NUMBER
A SENSOR LO 1
B SENSOR C + HI 2 + 3
SENSOR: HALL or PWM
Wiring for three wires (1 output) Hall sensor. If sensor has no internal source driver or has low
side (open collector) output with no internal pull up resistor, connect any small 4.7Kohm –
10Kohm resistor between its output and positive power lead. You can connect it directly
between terminal ports 2 - 3.
HALL SENSOR ROTATOR PORT NAME PIN NUMBER
GND SENSOR LO 1
OUTPUT SENSOR C 2
POWER + SENSOR HI 3
