Microlight TX Series - Size Parameters; Reading Parameters

14
Size parameters
Table 1-1 Appearance parameters
Parameter
Type
TX200
TX400
TX600
TX800
physical
dimension
95*84*48mm
95*70*48mm
134*92*50mm
88*67*48mm
Reading
window size
59*46mm
59*46mm
59*46mm
59*46mm
Installation
method
Embedded
installation
External
installation
Embedded
installation
Materials
ABS
ABS
ABS
ABS
Hole Size
67.5*88mm
Corner radius
4.27mm
67.5*88mm
Corner radius
4.27mm
108.2*86.2m
m, Corner
radius 2.1mm
Reading parameters
Table 1-2 Reading parameters
TX series QR Code Reading parameters
Image Sensor
300,000 pixel CMOS (640*480)
light source
Led diffuse lighting (white lighting, red indicator)
Instruction
Buzzer, three blue LED status indicators, red LED indication
Identification code
QR Code, Data Matrix, EAN_13, EAN_8, RSS_14, CODE_39,
CODE_93, CODE_128, ITF, Code Bar, Inverse Code, Mirror
Code, etc.
Print contrast
≥25%
Reading accuracy
≥7mil
Reading speed
70ms/times
Field of view angle
Horizontal field of view 77°, vertical field of view 60°
Reading angle
Tilt ± 40° , deflection ± 30° , rotate 360°
Depth of field
0mm~55mm（ 15mil QR Code）
