Device parameters
Table 1-3 Specific parameters
Technical indicators
Specific parameters
Microprocessor
32-bit 1G CPU, high-speed DDR memory
Data interface
RS232 (9.6 ~ 115.2kbps), USB1.1 (HID-KBW,
HID-POS), custom HID (add USB development
interface, high-speed transmission)
Data line
RS232 data line (USB power supply interface + DB9 data
interface), USB cable, TTL line
Operating temperature
-20~70 degrees Celsius
Storage temperature
-40 to 80 degrees Celsius
Humidity
Relative humidity 0%~95%
Ambient light intensity
0~80,000LUX
Operating Voltage
Supports 5~15V wide voltage input
Working current
0.15A (5V) or 0.05A (15v)
Maximum power
Consumption
0.75W
International Certification
FCC Part15 Class B,CE EMC Class
Maintenance Requirements
Support remote maintenance and online upgrade
Materials
Body: Imported PC window: Tempered glass
Operating System
Supports Windows (xp.7.8.10), Linux, Android, Mac, etc.
Chapter Ⅱ Wiring instructions
Pin definitions
