VacPrep 061 Specifications
Feb 2013 1-3
Specifications
The following table gives the specifications of the VacPrep 061 Degasser.
Table 1-1. Specifications
Characteristic Specification
Sample Tubes Up to 3.0-cm (1 3/16-in.) OD bulbs with 1/4-,
3/8-, or 1/2-in., 9mm, 12mm OD stems.
Heating Block
Temperature:
Temperature Accuracy:
10 ºC above ambient to 400
ºC
10 ºC
Electrical
Voltage:
Power:
Frequency:
100, 120, 220, 240 VAC 10%
250 VA maximum
50/60 Hz
Environment
Temperature:
Humidity:
10 to 35 ºC operating;
0 to 50 ºC non-operating
Up to 90% relative, non-condensing
Gases Used Helium, nitrogen, argon, or any other pure gas that does
not adsorb at room temperature.
Flow Rate
(flowing gas preparation)
Up to 50 cm
3
/min.
Vacuum System A vacuum source achieving better than 20 mHg at the
instrument inlet, and having a device to reduce oil vapor
backstreaming is recommended.
The vacuum system must also have an anti-suckback
valve to prevent oil from flowing into the VacPrep
should there be a power failure.
Sample Capacity Six ports, each with a heating and a cooling station
Physical
Height:
Width:
Depth:
Weight:
43 cm (16.95 in.)
36 cm (14.3 in.)
30 cm (11.87 in.)
10 kg (22 lbs)
