VacPrep 061 Selecting the Input Power
Feb 2013 1-5
Selecting the Input Power
All instruments leave the factory set for 120 VAC and with the line fuse removed. The correct
setting of the universal power entrance must be checked and the appropriate fuse installed
before the degasser can be operated. The degasser is designed to operate with 100, 120, 220, or
240 VAC at 50 or 60 Hz. Voltage selection and fusing are made at the power connector, which
is located on the rear panel of the unit.
1. Make sure the power cord is disconnected from the degasser.
2. Using a pointed object, remove the fuse block and cover assembly from the power
connector at the rear of the degasser.
3. Pull the voltage selector card straight out of the power connector housing.
The power cord should be disconnected from the degasser before removing the cover
from the input power connector. Failure to disconnect the power cord could result in
electrical shock.
