Page #16 background imageLoading...
Page #16 background image
Copyright Micropelt
Communication Profile MLR003RiEU61-07-1.116
8 Communication Profile MLR003RiEU61-07-1.1
FPort Number Type of operation Payload length Description Comments
0x00 MAC Commands 8 Bytes RESERVED
0x01
Valve position %
mode
Temperature
setpoint mode
(°C) with ambient
or external
temperature
sensor
Downlink:
6 Bytes
Uplink:
11 Bytes
Actuator
operation mode
with valve
position % only
Self-regulation
mode using the
requested
ambient setpoint
temperature
Strongly
recommended
to always use
an external
temperature
sensor
0x02 Report REV
Number, Hardware
and Firmware
Version
Downlink:
()
Uplink:
6 Bytes
Request REV
Number, Hardware
and Firmware
Version
Only
supported in
MLR003RiEU6
1-07-2.0
0x03 Motor operating
range
Downlink:
1 Byte
Uplink:
1 Byte
Set/change motor
operating range
(mm) from default
value 2,56mm
Only
supported in
MLR003RiEU6
1-07-2.0
0x04 LoRa Spread
Factor
Downlink:
1 Byte
Uplink:
1 Byte
Set/change LoRa
spread factor from
default value
Only
supported in
MLR003RiEU6
1-07-2.0
0x05 Slow Harvesting
(SH) and Valve
opening point
detection OPD)
Downlink:
1 Byte
Uplink:
1 Byte
Activate and report
OPD, activate/
deactivate Slow
Harvesting
Only
supported in
MLR003RiEU6
1-07-2.0
