Performance Data MLR003RiEU61-07-1.1 – 32
10 Performance Data MLR003RiEU61-07-1.1
Parameter Range
Ambient operating temperature 0 to 40°C, max 70% rH
Flow pipe temperature 75°C max
Transportation & storage temperature range -20 to +65°C, max 70% rH
Dimensions (LWH) 83 x 60 x 64 mm (63 x 60 x 64 without valve
connector)
Weight 280 g (not including packing)
Operation at high altitude Max 2000 m / 6500 ft above sea level
Max pin stroke (calibration range) > 5.5 mm
Operating pin stroke (0-100%) 2.56 mm typical
Pin Stroke Resolution Steps of 1%
Adjustment speed 0.727 mm/s typical
Stall force 100N
Noise level < 35 dB(A) @ 70 N load
Radio Communication Interval (default) 10 minutes
Radio Communication Interval during Installation Cycle 10 seconds for 5 minutes
Radio Communication attempt Interval (after join fail or
6 consecutive communication fails)
3 * 10 seconds
Then 2 minutes
Then 60 minutes
