Communication Profile MLR003RiEU61-07-1.1 – 17
8.1 FPORT 0x01 UPLINK: MLR003RiEU61-07-1.1 to Controller / Network Server
BYTE BIT RANGE SIZE OFFSE
T
ABB
REV.
DETAILS
1 DB0.7…0.0 8 0 CVP Current Valve Position %
0x00 … 0x64 / 0 … 100%
Res = 1%
2 DB1.7…1.0 8 8 FSR
V
Flow Sensor RAW Value °C
0x00 … 0xFF / 0 … 125.0°C
Res = 0.5°C
3 DB2.7…2.0 8 16 FTM
P
Flow TEMPERATURE Value °C
0x00 … 0xFF / 0 … 125.0°C
Res = 0.5°C
4 DB3.7…3.0 8 24 ASR
V
Ambient Sensor RAW Value °C
0x00 … 0xFF / 0 … 63.75°C
Res = 0.25°C
5 DB4.7…4.0 8 32 ATM
P
Ambient TEMPERATURE Value °C
0x00 … 0xFF / 0 … 63.75°C
Res = 0.25°C
6 DB5.7 1 40 RESERVED
DB5.6 1 41 ES Energy Storage is low
1 = Battery is low
DB5.5 1 42 HA Harvesting
1 = Harvesting is active
DB5.4 1 43 ASF Ambient Sensor Failure
1 = Sensor Failure
To Next Page
