Micropelt MLR003 User Manual

Copyright Micropelt
Communication Profile MLR003RiEU61-07-1.1 – 20
8.2 FPORT 0x01 DOWNLINK: Controller / Network Server to MLR003RiEU61-07-1.1
BYTE BIT
RANGE
SIZE OFFSE
T
ABBREV. DETAILS
1 DB0.7
…0.0
8 0 SPV Set Point Value according to User Mode
VALVE %: 0x00 … 0x64 / 0 … 100%
Res = 1%
AMB TEMP: 0x00 … 0x50 / 0 … 40°C
0x00 = Default = 0x28 = 20°C
Res = 0,5°C
2 DB1.7
…1.0
8 8 RT Room TMP from RCU °C
0x00 … 0xA0 / 0 … 40°C
0x00 = No Room TMP provided
Res = 0,25°C
3 DB2.7
…2.0
8 16 SSV Set Safety Value according to safety mode
AMB TEMP: 0x00 … 0x50 / 0 … 40°C
0x00 = Default = 0x28 = 20°C
Res = 0,5°C
VALVE %: 0x00 … 0x64 / 0 … 100%
Res = 1%
4 DB3.7 1 24  RESERVED
 DB3.6
…3.4
3 25 RCI Radio Communication Interval
0b000 = Default = 10 minutes
0b000 10 minutes
0b001 5 minutes
0b010 60 minutes
