Communication Profile MLR003RiEU61-07-1.1
–
21
0b011
120 minutes
0b100
480 minutes
0b1zz
RESERVED
DB3.3
…3.2
2
28
UM
User Mode
0b10 = Default = SP Ambient Temperature
0b00
Valve Position %
0b01
RESERVED
0b10
SP Ambient
Temperature °C
0b11
RESERVED
DB3.1
…3.0
2
30
SM
Safety Mode
0b00 = Default = SP Ambient Temperature
0b00
SP Ambient Temperature °C
0b01
RESERVED
0b10
Valve Position %
0b11
RESERVED
5
DB4.7
…4.4
4
32
FSOC
Offset Compensation Flow Sensor °C
-8°C … +7°C
0x00
+5°C (default)
0x01
+1°C
0x02
+2°C
20
22
Table of Contents
Table of Contents
2
Revision History Mlr003Rieu61-07-1.1
3
Use and Safety MLR003R
5
General Description MLR003R
6
Operating Modes MLR003R
8
Power Consumption MLR003R
10
Power Management MLR003R
11
Energy Harvesting
11
Device Power Management
11
Energy Storage
12
Forced Heating MLR003R
15
Slow Harvesting
15
Communication Profile Mlr003Rieu61-07-1.1
16
FPORT 0X01 UPLINK: Mlr003Rieu61-07-1.1 to Controller / Network Server
17
FPORT 0X01 DOWNLINK: Controller / Network Server to Mlr003Rieu61-07-1.1
20
FPORT 0X02 REV Number, Hardware and Firmware Version MLR003R
24
FPORT 0X03 Motor Operating Range MLR003R
25
FPORT 0X04 Lora Spread Factor MLR003R
26
FPORT 0X05 Slow Harvesting SH and Valve Opening Point Detection OPD MLR003R
27
Operating Instructions MLR003R
28
User Interface Functionality
28
Setting up a Gateway
28
Pairing the Device with a Room Controller or Gateway
29
Mounting Position and off
29
Attaching and Activating a Unit
29
Reset (from Normal Operation Only)
30
No Reset from Mounting Position
30
Removal from the Valve
30
Temperature Control Loop
30
Antifreeze
30
Battery Charging Flow Chart
31
Performance Data Mlr003Rieu61-07-1.1
32
Mechanical Interface to Circulation Valve Body MLR003R
35
CE Conformity Mlr003Rieu61-07-1.1
36
Labeling MLR003R
37
Product Label
37
NFC Tag Label
38
Accessories MLR003
39
MLR003-KEY Magnetic Switch
39
