Communication Profile MLR003RiEU61-07-1.1 – 19
 DB9.4 1 75 REF
C
Reference Run Completed
1 = Successfully Completed
 DB9.3…9.2 2 76  RESERVED
 DB9.1…9.0 2 78 UM User Mode
As set by the last received Downlink (DB3.3…
3.2)
 0b00 Valve Position %
0b01 RESERVED
0b10 SP Ambient Temperature °C
0b11 RESERVED
11 DB10.7…
10.0
8 80 UV User Value according to User Mode
As set by the last received Downlink (DB0.7…
0.0)
VALVE %: 0x00 … 0x64 / 0 … 100%
Res = 1%
AMB TEMP: 0x00 … 0x50 / 0 … 40°C
Res = 0,5°C

