6 M1179886
General Information, Precautions, Warnings
This symbol identies important safety and health information in this manual.
This symbol identies important information in this manual.
This symbol identies important cautions in this manual.
Service Tools and Jigs
Microsoft Recommended Service Jigs
• ESD-safe battery cover
Microsoft Provided Software Tools / References:
• Software Tool – AB-cover Touch Calibration tool
• How To: Update Surface device rmware and OS
• How To: Surface Tools Video
• Download: Surface drivers and rmware
• Download: Surface Diagnostic Toolkit (SDT)
• Download: Surface Data Eraser
• Download: Surface Imaging Tools
Standard Service Tools:
• Anti-static wrist strap (1 MOhm resistance)
• ESD-safe benchtop
• Surface Laptop Power Supply
• USB hub (3 ports required)
• USB keyboard (standard PC keyboard)
• USB mouse (standard PC mouse)
• Standard PC monitor with HDMI or DVI input
• Mini-DP port to HDMI/DVI dongle
• Spudger tool
• Clamps (2), 50.8mm (2 in) spring
• Torx plus drivers 3IP,5IP,6IP
• Isopropyl alcohol dispenser bottle (use 70% IP A)
• Cleaning swabs
• ESD-safe tweezers
• Guitar pick opening tool
• Heavy duty suction cups (2) – 57.15mm (2.25 in)
• Plastic feeler gauge – 0.40mm
• Plastic feeler gauge – 0.50mm
• Plastic feeler gauge – 0.050mm
The tools identied on this list can be purchased from many different commercial sources, including but not limited
to Amazon.com; iFixit; Chemdex, and other vendors.
