36 ScanMaker 9800XL Plus User Guide
System Requirements
General Requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 512 MB RAM or more
PC and compatibles
• Pentium IV PC or higher with Hi-Speed USB (USB 2.0) port
• Microsoft Windows XP, Vista or Windows 7
Macintosh
• Intel-Based Mac computer with built-in USB port
• Mac OS X 10.6 through 10.7
Specifications
Scanning Modes Color, grayscale, and black-and-white in a single
scanning pass
True 48-bit color (approx. 281 billion colors)
16-bit grayscale (approx. 65,536 shades of gray)
Scanning Area Reflective: 12" x 16.9" (305 mm x 429.26 mm)
Transparent: 12" x 16" (305 mm x 405 mm)
Resolution Optical: 1600 (H) dpi x 3200 (V) dpi
Dynamic Range 3.6 Dmax
Interface Hi-Speed USB (USB 2.0)
Dimensions (L x W x H) 24.7" x 14.8" x 5.1" ( 627.5 x 375.9 x 129.5 mm);
24.7" x 14.8" x 7.1" ( 627.5 x 375.9 x 180.5 mm)
(with TMA 1600-III)
Weight 26.4 lbs / 12 kg;
35.4 lbs / 16.1 kg (with TMA 1600-III)
Voltage AC 100V-240V, 47-63 Hz, 1.5 A max.
Power Consumption 54.9 W max.
Environment Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
Important
Specifications, software bundles, and accessories are subject to change without
notice. Not responsible for typographic errors.
