Midas XL8

Location of the navigational controls 23
XL8 Control Centre
Quick Reference Guide
Figure 9: Mix bay navigational controls
Mix bay
5
3
4
1
1
3
1
1
1
1
2
1
1
Key:
1 Quick access button
2 LCD select button
3 Scroll buttons
4 Output channel select buttons (returns
and auxes)
5 LED indicators — show currently
selected bank of outputs (returns,
auxes or matrices)
