Location of the navigational controls 21
XL8 Control Centre
Quick Reference Guide
Location of the navigational controls
This section shows the position of the control surface navigational controls per bay.
Figure 7: Input bay navigational controls (channel)
Key:
1 Quick access button
2 LCD select button
3 Scroll buttons
4 Numeric keypad
5 LED indicators — show which bank
of inputs is currently selected.
When a group is selected, an LED
will flash if its bank contains a
group member that is not
currently at the control surface.
1
1
1
1
1
1
1
1
1
1
2
3
5
3
4
Input bay
