Manual Number 9018233 Revision C, February 21, 2022 5
1.2 TECHNICAL SPECIFICATIONS
Electrical Attributes
Input Voltage: 10-32 VDC
Input Power: 4 watts (0.12A @ 28VDC)
Output Power: Reserved for MD32 Remote Magnetometer (pin 11)
Lighting Input: n/a
Input Data: ARINC 429 (see Table 1.1)
Output Data: ARINC 429 (see Table 1.1);
discrete valid signal to ground; invalid signal is open (pin 2)
Physical Attributes
Weight: 1.3 pounds (0.59 kg)
Dimensions:
(without connectors, mates & knob)
Bezel: 2.30” x 5.20” x 0.125” (HxWxD)
Chassis: 2.31” x 3.16” x 4.84” (HxWxD)
Mating Connectors: 15-pin D-Sub with Configuration Module, MCIA p/n 9017275
Pneumatic fittings, MCIA p/n 9017642
Mounting: Mount from front; uses (4) #6-32 screws
Performance Limits
ttitude: Pitch Angle No limits (360°+)
Pitch Rate 300° per second max
Roll Angle No limits (360°+)
Roll Rate 300° per second max
ltitude: Range -1,500 to +55,000 feet (available in meters)
Baromete
28.00 to 31.00 inches of mercury (available in mbar)
irspeed: Range 20 to 500 knots (available in mph or kph)
Qualifications
Certifications: FAA TSO-C2d (Type B), C3e, C4c, C6e, C10b, C106, C113a,
C179a
EASA ETSO-C2d, C3d, C4c, C6e, C10b, C106, C113, C179a
Environmental Qualification: RTCA DO-160G (details listed in Section 5.2)
Software Qualification: RTCA DO-178B, Design Assurance Level
Complex Hardware Qualification: RTCA DO-254, Design Assurance Level
Rights
U.S. Patent No.: 9,739,611
