Midcontinent MD302-3 User Manual

Manual Number 9018233 Revision C, February 21, 2022 25
5.2 ENVIRONMENTAL QUALIFICATION STATEMENT
MODEL NUMBER: MD302 Series PART NUMBER: 6420302-( )
DESCRIPTION: 2-inch Standby Attitude Module (SAM)
CERTIFICATION: FAA TSO-C2d (Type B), C3e, C4c, C6e, C10b, C106, C113a, C179a
MANUFACTURER: Mid-Continent Instrument Co., Inc.
ADDRESS: 9400 E. 34
th
St. North, Wichita, KS 67226, USA.
SPECIFICATION: Test Specification (TS) 302 Test Data Sheet (TDS) 302
STANDARD: RTCA DO-160, Rev G, dated 12/08/2010
CONDITIONS SECTION DESCRIPTION OF TEST
Temperature and Altitude 4 Category B2
Temperature Variation 5 Category S2
Humidity 6 Category A
Operational Shock and Crash Safety 7 Category B
Vibration 8 Fixed Wing: Category R, Curves B, B1
Rotorcraft: Category U, Curve G
Explosion 9 Category X
Waterproofness 10 Category X
Fluids 11 Category X
Sand and Dust 12 Category X
Fungus 13 Category F
Salt Fog 14 Category X
Magnetic Effect 15 Category Z
Power Input 16 Category Z
Voltage Spike 17 Category A
Audio Frequency Conducted Susceptibility 18 Category Z
Induced Signal Susceptibility 19 Category ZC
Radio Frequency Susceptibility 20 Category Y
Category G
Emission of Radio Frequency Energy 21 Category P
Lightning Induced Transient Susceptibility 22
Category B3
Category H3L3, K3L3
Lightning Direct Effects 23 Category X
Icing 24 Category X
ESD 25 Category A
Fire, Flammability 26 Category X
REMARKS:
Section 4: Category B2 with excursions as declared by the manufacturer:
 4.5.1: Ground Survival Low Temp -45°C
 4.6.1: Altitude +55,000 feet
 4.6.2: Decompression +8,000 feet
 4.6.3: Overpressure -15,000 feet
