HEADING OPERATION
Flight Mode / HEADING OPERATION
Image 6
Roll/Bank Scale
Symbolic Airplane
Heading Scale
Pitch Scale
Horizon Line
Heading Window
Slip Indicator
Heading Operation can be congured during installation. The
heading information is comprised of a window showing the current
heading and a moving scale located along the bottom of the
display (Image 6). The Heading Scale is depicted as a series of
graduations every 10° with numbers every 30°, and letters for each
cardinal heading.
REV. F Sept 15, 2015 Manual Number 9017846
