Midcontinent SAM MD302 - Product Specifications

Power Input 10-32 VDC; 6W nominal, 25W max
Output ARINC 429 (high or low speed, see manual for specic labels)
Operating Range
Attitude 300° per second pitch, roll and yaw (max)
Altitude -1,500 to +55,000 ft (-457 m to 16,764 m)
Airspeed 20 to 500 knots (23 to 575 mph) (37 to 926 kph)
Heading Displayed via ARINC 429 input (external interface dependant)
Units of Measure
Altitude Feet or meters
Barometric Setting Inches of mercury, millibars
Airspeed Knots, miles per hour or kilometers per hour
Panel Tilt Congurable -90° to +90° pitch
Panel Roll Congurable ±5° roll
Lighting 5, 14 and 28 VDC external input or internal photocell
Programmable dimming curve
Pilot Interface 16-detent, push and turn knob
Weight 1.6 lbs (0.73 kg)
Battery Rechargeable, eld-replaceable, internal battery
Technology Lithium iron phosphate
Run time 60 minutes minimum when fully charged and properly
maintained
Mounting Front panel mounted
Mating Connectors Mid-Continent P/N 9017646 kit contains custom
DB15 connector with conguration module, pitot and
static connectors
Certication
FAA TSO certied to C2d, C3e, C4c, C10b, C106, C113a, C179a
ANAC TSO certied to C2d, C3e, C4c, C10b, C106, C113a, C179a
EASA ETSO certied to C2d, C3d (incomplete), C4c, C10b, C106, C113, C179a
RTCA DO-178B and DO-254 Design Assurance Level (DAL) A
RTCA DO-160 and RTCA DO-311 qualied
PRODUCT SPECIFICATIONS
REV. F Sept 15, 2015 Manual Number 9017846
