Options Menu / ATTITUDE SYMBOL
The Symbol setting allows the user to select the type of symbolic
airplane on the Attitude Display to either delta-wing or traditional.
This feature is provided for pilot preference and to match other
instruments in the panel (Images 15, 16, 17).
DELTA-WING SYMBOL
TRADITIONAL SYMBOL
Image 15
REV. F Sept 15, 2015 Manual Number 9017846
21
Image 16 Image 17
