CCM-180A/WS
4
201803
CCM
-180A/WS Service Manual
2
Packing
List
Name
Qty (specif
ication)
Adapter
x1 (output
12V DC)
Manual
x1
Cable tie
x1
Scre
w
x4 (ST3.9
*16)
Centr
alized
con
troller
x1
2.1
Specificatio
ns
T
a
ble 1 Specifications
Adapte
r
Input (AC)
100-240V
, 50/60Hz, 800mA
Output (DC)
12.0V
, 2A
Centr
aliz
ed
contr
oller
Input vo
ltag
e
12VDC
Ambient
T
empera
ture
23~110°
F (-5~43°
C)
Ambient
Humidity
RH40%~RH
90%
Dimensions
(
mm
)
181x124x
30
4
6
Table of Contents
Table of Contents
2
General Safety Precautions
3
General
3
Installation Site
3
Electrical
3
Packing List
5
Specifications
5
Installation Procedure
6
Mounting the Controller
6
Centralized Controller Wiring Diagram
8
Debugging the Centralized Controller
9
Getting Started
10
Home Page Button and Display Description
10
Control Page
13
Schedule
20
Fault Report Page
25
Installation Interface
28
Settings Page
31
Help Interface
43
