Midea CCM-180A/WS User Manual

1 CCM-180A/WS
201803 5
CCM
-180A/WS Service Manual
3 Installation Procedure
Figure 1 Front view and back view of the centralized controller (unit: mm)
3.1 Mounting the Controller
3.1.1 Remove the back cover from the controller using a Phillips-head screwdriver. See Figure 2.
Figure 2 Remove back cover from controller
3.1.2 Attach the back cover to the wall using screws. See Figure 3.
Figure 3 Attach back cover to wall
