1. Measurements
Outdoor units
Model name
Dimension (mm)
Net/Gross weight (kg)
Power supply
CE-LRSJF-V120/N1-610
Width: 900
Height: 1327
Depth:348
89/101
220～240-50Hz
1 Ph
CE-LRSJF-V100/N1-610
CE-LRSJF-V80/N1-310
Width: 895
Height: 862
Depth:313
66/70
220～240-50Hz
1 Ph
CE-LRSJF-V60/N1-310
CE-LRSJF-V80/N1-310-B
Width: 895
Height: 862
Depth:313
63/67
220～240-50Hz
1 Ph
Hydraulic indoor unit
SMK-120/CD30GN1
Width: 900
Height:500
Depth:375
63/75
220～240-50Hz
1 Ph
SMK-100/CD30GN1
SMK-80/CD30GN1
SMK-60/CD30GN1
SMK-80/CSD80GN1
Width: 900
Height:500
Depth:375
64/77
380V-3Ph-50Hz
Solar kit
CE-TMK-01
Width: 810
Height: 310
Depth:295
8/10
220～240-50Hz
1 ph
Water Tank
Model name
Dimension (mm)
Net/Gross weight (kg)
Packing Dimension W×D×H
CE-LSX-300XP/D30B11
Ф580×1800
75//84
620×1960×635
CE-LSX-200XP/D30B11
Ф580×1320
60/68
670*1400*670
CE-LSX-150XP/D30B7
Ф580×1055
49/55
670*1135*670
CE-LSX-300XP/SD15B11
Ф580×1800
80/91
670×1885×670
