Midea CE-LRSJF-V80/N1-310

MCAC-RTSM-2009-09 Midea Heat Pump Water Heater Technical Manual
31
No.
Part Name
No.
Part Name
1
Bottom
18
Outlet pipe fixed plate
2
Flip
19
Right foam refrigerant pipe
3
Decorative ring
20
Target flow switch
4
Decorative plates
21
Left foam refrigerant pipe
5
Magnet sets
22
Right out of the bubble pipe
6
Roof
23
Left out of the bubble pipe
7
Front Panel
24
Electronic control box mounting plate
8
E-part box ass'y
25
Electronic control box mounting plate
8.1
Main control board ass'y
26
Water tray components
8.2
Wire joint, 6p
27
Connect hose
8.3
32A MCB
28
Safety valve
8.4
AC contactor
29
Electric water heating tube
8.5
Transformer
30
Exhaust valve
8.6
Wire joint, 5p
31
Small water tank
8.8
E-part box ass'y
32
Outlet pipe components
8.9
Thirty Terminal Block
33
Expansion Tank
8.10
Contactor
34
Electric valve
8.11
Wire joint
35
Wired remote support
9
Electronic control box cover
36
Electric heating cover
10
Rear
37
Pump Bracket 2
11
Casing components
38
Pump bracket
11.1
Inlet components
39
Hydraulic module wired remote
11.2
Tracheal components
40
Expansion Tank take over the components
11.3
Tube heat exchanger
41
Pipe temperature sensor assemblies
11.4
Liquid tube assemblies
42
Small water tank fixed plate
12
Pump mounting plate
43
Temp sensor
13
Handle
44
Thermostat components
14
Refrigerant pipe fixed plate
45
Drain Pump
15
Mounting Bracket
46
Hydraulic meter
16
Fixed plate inlet
47
Manual ball valve
17
Expansion tank clamp
