Midea MDV-V80W/DN1 Technical Manual

R410A All DC Inverter Mini VRF MCAC-VTSM-2014-10
12 Specifications & Performance
Sale Model
MDV-V80W/DN1
MDV-V105W/DN1
MDV-V120W/DN1
Outdoor air flow
m
3
/h
5500
5500
6000
Outndoor sound level(sound
pressure level )
dB(A)
54~67
54~68
57
Indoor unit connectable (Total Capacity)
45%~130%
45%~130%
45%~130%
Max. quantity of indoor unit
4
5
6
Outdoor unit
Dimension
(W×H×D)
mm
1075×966×396
1075×966×396
900×1327×400
Packing
(W×H×D)
mm
1120×1015×435
1120×1015×435
1030×1456×435
Net/Gross weight
kg
75.5/85.5
75.5/85.5
95/106
Refrigerant
Type
R410a
R410a
R410A
Charged volume
g
2950
2950
3300
Throttle type
Electronic expansion valve
Design pressure
MPa
4.4/2.6
4.4/2.6
4.4/2.6
Refrigerant
piping
Liquid side/ Gas
side
mm
Ф9.52/Ф15.9
Ф9.52/Ф15.9
Ф9.52/Ф15.9
Max. refrigerant
pipe length
m
100
100
100
Max. difference in
level
m
8
8
8
Connection
wiring
Power wiring
mm
2
3 core × 4.0
3 core × 4.0
3 core× 4.0
Signal wiring
mm
2
3 core shielded wire
× 0.75
3 core shielded wire ×
0.75
3 core shielded wire
×0.75
Ambient temperaure
℃
（Cooling -15～43）（Heating -15～27）
Sale Model
MDV-V140W/DN1
MDV-V160W/DN1(B)
Code
220095100891
220095102360
Power supply
V-Ph-Hz
220-240V~50Hz
220-240V~50Hz
Cooling
Capacity
kW
14
15.5
Input
kW
3.95
4.52
EER
W/ W
3.54
3.43
SEER
kW/ kW
----
----
Heating
Capacity
kW
15.4
17
Input
kW
4.16
4.77
COP
kW/ kW
3.70
3.56
SCOP
W/ W
----
----
Max. input consumption
W
6440
7100
Max. current
A
29.8
28.6
Compressor
Model
TNB306FPGMC
LNB42FSCMC
Type
Rotary
Rotary
Brand
MITSUBISHI
MITSUBISHI
Capacity
Btu/h
33642
47700
Input
W
3010
4240
Rated
current(RLA)
A
13.5
16.1
Crankcase
W
25
25
Refrigerant oil
ml
FV50S
870ml+630ml
FV50S
1400ml+250ml
Outdoor fan
motor
Model
WZDK100-38G
WZDK100-38G
Type
DC motor
DC motor
Brand
Panasonic
Panasonic
