Midea MDV-V80W/DN1 Technical Manual

MCAC-VTSM-2014-10 R410A All DC Inverter Mini VRF
Specifications & Performance 11
1. Specifications
Sale Model
MDV-V80W/DN1
MDV-V105W/DN1
MDV-V120W/DN1
Code
220095103431
220095103351
220095101631
Power supply
V-Ph-Hz
220-240V~50Hz
220-240V~50Hz
220-240V~50Hz
Cooling
Capacity
kW
7.2 (1.5~8)
9.0 (2~10)
12.3
Input
kW
1.82 (0.71~1.86)
2.3 (0.89~2.59)
3.25
EER
kW/ kW
3.95
3.91
3.78
SEER
W/W
5.1
5.3
----
Heating
Capacity
kW
7.2 (1.6~8.4)
9.0 (2.1~10)
13.2
Input
kW
1.76 (0.83~2.11)
2.27 (1.06~2.77)
3.47
COP
kW/ kW
4.09
3.97
3.80
SCOP
W/W
3.8
3.8
----
Max. input consumption
W
3775
4716
5319
Max. current
A
18.5
22.8
24.4
Compressor
Model
TNB220FLHMC
TNB220FLHMC
TNB306FPGMC
Type
Rotary
Rotary
Rotary
Brand
MITSUBISHI
MITSUBISHI
MITSUBISHI
Capacity
Btu/h
24334
24334
33642
Input
W
2200
2200
3010
Rated
current(RLA)
A
9.7
9.7
13.5
Crankcase
W
25
25
25
Refrigerant oil
ml
FV50S 670ml+200ml
FV50S 670ml+200ml
FV50S 870ml+630ml
Outdoor fan
motor
Model
WZDK170-38G-1
WZDK170-38G-1
WZDK100-38G
Type
DC Motor
DC Motor
DC motor
Brand
Panasonic
Panasonic
Panasonic
Insulation class
E
E
E
Safe class
IPX4
IPX4
IP23
Input
W
195
195
2*100
Output
W
170
170
2*85
Rated current
A
1.6
1.6
2*0.9
Speed
r/min
820
820
800
Outdoor fan
Material
ASG20
ASG20
ASG20
Type
Axial fan
Axial fan
Axial fan
Diameter
mm
560
560
508
Height
mm
170
170
170
Outdoor coil
Number of rows
2
2
2
Tube pitch(a) ×
row pitch(b)
mm
25.4 × 22
25.4 × 22
22 ×19.05
Fin spacing
mm
1.6
1.6
1.6
Fin type (code)
Hydrophilic aluminum
Tube outside
dia.and type
mm
Ф9.52
Ф9.52
Ф7.94
Inner groove tube
Inner groove tube
Inner groove tube
Coil length ×
height
mm
880×914
880×914
1276×870
Number of circuits
5
5
7
