Midea MDV-V80W/DN1 Technical Manual

MCAC-VTSM-2014-10 R410A All DC Inverter Mini VRF
Specifications & Performance 13
Sale Model
MDV-V140W/DN1
MDV-V160W/DN1(B)
Insulation class
E
E
Outdoor Fan
motor
Safe class
IP23
IP23
Input
W
2*100
2*100
Output
W
2*85
2*85
Rated current
A
2*0.9
2*0.9
Speed
r/min
800
800
Outdoor fan
Material
ASG20
ASG20
Type
Axial fan
Axial fan
Diameter
mm
508
508
Height
mm
170
170
Outdoor coil
Number of rows
2
2
Tube pitch(a) ×
row pitch(b)
mm
22 ×19.05
22 ×19.05
Fin spacing
mm
1.6
1.6
Fin type (code)
Hydrophilic aluminum
Tube outside
diameter and type
mm
Ф7.94
Ф7.94
Inner groove tube
Inner groove tube
Coil length ×
height
mm
1276×870
1276×870
Number of circuits
7
7
Outdoor air flow
m
3
/h
6000
6000
Outndoor sound level(sound
pressure level )
dB(A)
57
57
Indoor unit connectable (total capacity)
45%~130%
45%~130%
Max. quantity of indoor unit
6
7
Outdoor unit
Dimension
(W×H×D)
mm
900×1327×400
900×1327×400
Packing
(W×H×D)
mm
1030×1456×435
1030×1456×435
Net/Gross weight
kg
95/106
100/111
Refrigerant
Type
R410A
R410A
Charged volume
g
3900
3900
Throttle type
Electronic expansion
valve
Electronib expansion
valve
Design pressure
MPa
4.4/2.6
4.4/2.6
Refrigerant
piping
Liquid side/ Gas
side
mm
Ф9.52/Ф15.9
Ф9.52/Ф19.1
Max. refrigerant
pipe length
m
100
100
Max. difference in
level
m
8
8
Connection
wiring
Power wiring
mm
2
3 core × 4.0
3 core × 4.0
Signal wiring
mm
2
3 core shielded wire ×
0.75
3 core shielded wire× 0.75
Ambient temperature
℃
（Cooling -15～43）（Heating -15～27）
Notes:
1. The cooling conditions: indoor temp.: 27℃DB (80.6℉), 19℃WB (66.2℉) outdoor temp.: 35℃DB (95℉), 24℃WB (75.2℉)
equivalent pipe length: 5m drop length: 0m.
2. The heating conditions: indoor temp.: 20℃DB (68℉), 15℃WB (59℉) outdoor temp.: 7℃DB (44.6℉), 6℃WB (42.8℉)
equivalent pipe length: 5m drop length: 0m.
3. Sound level: Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height of *m(1m for 80/105
model,1.2m for 120~160 model). During actual operation, these values are normally somewhat higher as a result of ambient
conditions.
4. The above data may be changed without notice for future improvement on quality and performance.
