Midea MOUA-96HD1N1-R User Manual

R410A Full DC Inverter Split Duct Type Technical Manual MCAC-UTSM-201503
13
2. Specifications
Model
MHC-96HWD1N1(A)
Power supply
V, Ph, Hz
220~240V,1Ph,50Hz
Cooling
Capacity
W
28,000
Input
W
9,000
EER
W/W
3.11
Heating
Capacity
W
31,500
Input
W
8,500
COP
W/W
3.71
Rated input
W
850
Rated current
A
4.5
Indoor fan motor
Model
\
WZDK750-38GS-W
Brand
\
Panasonic
Quantity
\
1
Speed
r/min
1200/1160/1090
Indoor coil
Number of rows
\
4
Tube pitch(a)×row pitch(b)
mm
25.4×22
Fin spacing
mm
1.5
Fin type
\
Hydrophilic aluminum fin
Tube size
mm
Ф9.52
Tube type
\
Inner grooved copper pipe
Coil(W×H)
mm
1,202×457.2
Number of circuits
\
18
Indoor air flow
m3/h
3000~4800
External static pressure
Pa
0~150
Indoor noise level
dB(A)
49~52
Refrigerant
\
R410A
Design pressure
MPa
4.4/2.6
Refrigerant pipe
Liquid side/ Gas side
mm
Ф9.52/Ф25.4
Max. refrigerant pipe length
m
50
Max. difference in level (Outdoor upper)
m
25
Max. difference in level (Outdoor lower)
m
30
Connection wire
Power wire
\
5×4.0mm2(outdoor) 3×2.5mm2(indoor)
Signal wire
\
3×0.75mm
2
Drain pipe size (OD)
mm
Ф31(outdoor) Ф33(indoor)
Controller
\
KJR-29B1/BK-E (Wired controller)
Operation temperature
°C
17～30
Indoor unit
Dimension (WxHxD)
mm
1,470×512×775
Packing (WxHxD)
mm
1,555×545×875
Net/Gross weight
kg
83/92
Note:
1. The nominal cooling capacity is based on the following conditons.
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°CWB.
2. The nominal heating capacity is based on the following conditons.
Indoor temperature: 20°CDB, 15°CWB; Outdoor temperature: 7°CDB, 6°CWB
3. The noise is measured in the semi noise suppression lab.
4. Specifications are subject to change without prior notice for product improvement.

Midea MOUA-96HD1N1-R Specifications

General

Brand	Midea
Model	MOUA-96HD1N1-R
Category	Air Conditioner
Language	English
