MCAC-UTSM-201503 R410A Full DC Inverter Split Duct Type Technical Manual
8
3. Refrigerant circuit
High pressure
switch
Oil seperator
Oil return
capilary
Compressor
Low pressure
switch
Low pressure
liquid
accumulator can
Condensor
High pressure
liquid
accumulator
can
Electronic
expansion
valve
Evaporator
SV5
SV6
