MCAC-UTSM-201503 R410A Full DC Inverter Split Duct Type Technical Manual
6
1. Specifications
Model
MOUA-96HD1N1-R
Power supply
V, Ph, Hz
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
-15～48
Ambient temp in heating
°C
-15~24
Rated input (Whole units)
W
11,700
Rated current (Whole units)
A
16
Compressor
Model
LNB53FCAMC
Type
Rotary
Brand
MITSUBISHI
Quantity
1
Capacity
kW
16.86
Input
kW
5.2
Crankcase heater
W
25
Refrigerant oil type
FV50S
Refrigerant oil charge
ml
1700+1500
Outdoor fan motor
Model
WZDK170-38G-1
Type
DC
Quantity
2
Brand
Panasonic
Insulation class
E
Safe class
IP×4
Input
W
250(up)/185(down)
Output
W
200(up)/150(down)
Rated current
A
1.7(up)/1.4(down)
Outdoor fan
Material
Plastic
Type
Axial fan
Quantity
mm
2
Diameter
mm
560
Height
170
Outdoor coil
Number of rows
2
Tube pitch(a)×
row pitch(b)
mm
21×19.4
Fin spacing
mm
1.5
Fin type
Hydrophilic fin
Tube outside diameter
mm
Ф7
Tube type
Inner groove tube
Coil length×height
mm
1080 x 756
Number of circuits
18
Outdoor air flow
m3/h
9800
Sound pressure level
dB(A)
59
Outdoor uint
Net dimension
(W×H×D)
mm
1120×1558×528
Packing
(W×H×D)
mm
1270×1720×565
Net/Gross weight
mm
147/163
Refrigerant
Type
R410A
Factory charged
kg
7.2
Throttle type
Electronic expansion valve
Design pressure (Hi/Lo)
MPa
4.4/2.6
Refrigerant piping
Liquid pipe
mm
Ф9.53
Gas pipe
mm
Ф25.4
Note:
1. The nominal cooling capacity is based on the following conditons.
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°CWB.
2. The nominal heating capacity is based on the following conditons.
Indoor temperature: 20°CDB, 15°CWB; Outdoor temperature: 7°CDB, 6°CWB
3. The noise is measured in the semi noise suppression lab.
4. Specifications are subject to change without prior notice for product improvement.
