R410A Full DC Inverter Split Duct Type Technical Manual MCAC-UTSM-201503
31
pipe to completecentralized drainage installation.
3.4 Install the connecting pipe of outdoor
Check whether the height drop between the indoor unit and outdoor unit, the length of refrigerant pipe,
and the number of the bends meet the following requirements:
The indoor and outdoor connecting pipe interface and power line outlet
Vavious piping and viring patterns can be selected,such as out from the front ,the back the side ,and
undersurface, etc.(The follow display the locations of several piping and wiring knock-off interfaces)
3.5 Leak Detection
Use soap water or leak detector to check every joint whether leak or
not.Note:
A is low pressure side stop valve
B is high pressure side stop valve
Sealing ring for the
water outlet union pipe
Waterproof chassis cover
Front out pipe Side out pipe
