Midea MOX133-09HFN8-QRD0GW User Manual

 T
roubleshooting 5 
6 times FLASH
P5/--
Indoor units mode conflict(match with multi outdoor unit) TS14
7 times FLASH
P6
Low pr
essure protection TS13-INV
-- --
P10
Over low voltage protection TS10-S
-- --
P11
Over voltage protection TS10-S
Running
Lamp
Timer
Lamp
Display Err
or Information Solution
-- --
F
Defr
ost --
-- --
SC
Self clean --
-- --
CL
Filter cleaning reminder(power on display for 15 seconds) --
-- --
F
Filter r
eplacement reminder(power on display for 15 seconds) --
-- --
FP
Heating in room temperature under 8°C&12°C --
-- --
FC
Forced cooling --
-- --
AP
AP mode of WIFI connection --
-- --
CP
Remote switched off --
1 time OFF
EH 00/EH 0A
Indoor unit EEPROM parameter error TS01-IDU
2 times OFF
EL 01
Indoor/outdoor unit communication error TS02-S-INV
3 times OFF
EH 02
Zero-crossing signal detection error TS03
4 times OFF
EH 03
The indoor fan speed is operating outside of the normal range TS04-S-IDU
5 times OFF
EC 51
Outdoor unit EEPROM parameter error TS01-ODU
5 times OFF
EC 52
Condenser coil temperature sensor T3 is in open circuit or has
short circuited
TS05-ODU
5 times OFF
EC 53
Outdoor room temperature sensor T4 is in open circuit or has short
circuited
TS05-ODU
5 times OFF
EC 54
Compressor discharge temperature sensor TP is in open circuit or
has short circuited
TS05-ODU
5 times OFF
EC 56
Evaporator coil outlet temperature sensor T2B is in open circuit or
has short circuited(for free-match indoor units)
TS05-ODU
6 times OFF
EH 60
Indoor room temperature sensor T1 is in open circuit or has short
circuited
TS05-IDU
6 times OFF
EH 61
Evaporator coil middle temperature sensor T2 is in open circuit or
has short circuited
TS05-IDU
12 times OFF
EC 07
The outdoor fan speed is operating outside of the normal range TS04-ODU
9 times OFF
EH 0
Indoor PCB/Display boar
d communication error TS07
8 times OFF
EL 0C
Refrigerant leakage detection TS06-INV
7 times FLASH
PC 00
IPM malfunction or IGBT over-strong current protection TS09-S
2 times FLASH
PC 01
Over voltage or over low voltage protection TS10-S
3 times FLASH
PC 02
Top temperature protection of compressor or High temperature
protection of IPM module or High pressure protection
TS11-S-INV
5 times FLASH
PC 04
Inverter compressor drive error TS12-S
1 time FLASH
PC 08
Current overload protection TS08-S
6 times FLASH
PC 40
Communication error between outdoor main chip and compressor
driven chip
TS33
7 times FLASH
PC 03
Low pressure protection TS13-INV
1 times ON
--
Indoor units mode conflict(match with multi outdoor unit) TS14

Midea MOX133-09HFN8-QRD0GW Specifications

General

Brand	Midea
Model	MOX133-09HFN8-QRD0GW
Category	Inverter
Language	English
